Description
Technical Specifications
| Model | TL-SG2008 V4 |
|---|---|
| General | Interface |
| Flash | 32 MB |
| DRAM | 256 MB |
| Port Standard | IEEE 802.3i:10BASE-T Ethernet; IEEE 802.3u:100BASE-X Fast Ethernet; IEEE 802.3ab:1000BASE-T Gigabit Ethernet; IEEE 802.3z:1000BASE-X Gigabit Ethernet (Optical fiber) (only for TL-SG2210P) |
| PoE | PoE Standard |
| PoE Ports | 4, up to 30 W |
| PoE Power Budget | 62 W |
| Performance | Switching Capacity |
| Packet Forwarding Rate |
11.90 Mpps |
| MAC Address Table | 8K |
| Packet Buffer | 4.1 Mbit |
| Transmission Method |
Store and Forward |
| Number of IP Interfaces |
16 |
| Number of Static Routers |
32 (IPv4, IPv6) |
| Jumbo Frame | 9 KB |
| Physical & Environment |
Power Supply |
| Max Power Consumption |
6.4 W (220 V/50 Hz) |
| Max Heat Dissipation |
21.84 BTU/hr (220 V/50 Hz) |
| Standby Power Consumption |
2.56 W (220 V/50 Hz) |
| Dimensions (W x D x H) |
8.2 × 4.9 × 1.0 in (209 × 126 × 26 mm) |
| Fan Quantity | Fanless |
| Installation | Desktop/Wall-Mounting |
| Operating Temperature |
0 °C to 40 °C (32 °F to 104 °F) |
| Storage Temperature |
-40 °C to 70 °C (-40 °F to 158 °F) |
| Operation Humidity | 10% to 90% RH, non-condensing |
| Storage Humidity | 5% to 90% RH, non-condensing |
| Certification | CE, FCC, RoHS |
