Technical Specifications
| Main Processor | Embedded Processor |
|---|---|
| Operating System | Embedded Linux OS |
| Button Type | Mechanical |
| Interoperability | CGI;ONVIF |
| Network Protocol | FTP;RTMP;HTTP/HTTPS;DNS;RTSP;SSH;ONVIF;SIP;RTP |
| Screen Type | Non-touchscreen |
| Display Screen | 4.3-inch display screen |
| Screen Resolution | 800 (H) × 480 (V) |
| Camera | 1/2.8″ 2MP CMOS high-definition, low illumination, cameras |
| Field of View | H: 95°; V: 50°; D: 110° |
| WDR | 120 dB |
| Noise Reduction | 3D NR |
| Video Compression | H.264; H.265 |
| Video Resolution | Main stream: 720P/D1/WVGA; Sub stream: 1080P/720P/D1/WVGA/CIF/QVGA |
| Video Frame Rate | 25 fps |
| Video Bit Rate | 1,024 kbps–8,192 kbps |
| Light Compensation | Auto white light |
| Audio Compression | G.711a; G.711u; PCM |
| Audio Input | 1 channel |
| Audio Output | Built-in speaker |
| Audio Mode | Two-way audio |
| Audio Enhancement | Echo suppression/digital noise reduction |
| Audio Bit Rate | 16 kHz, 16 bit |
| Communication Mode | Full digital |
| Verification Method | Remote;Card;Password |
| Auto Snapshot | Yes |
| Information Release | Receive and view text information released by the management center. |
| Leave Videos | Yes (SD card inserted in VTH is needed) |
| Web Configuration | Yes |
| Auto Registration | Yes |
| Card Type | IC card |
| Card Reading Distance | 0 cm–4 cm (IC card) |
| Issue Card Locally | Yes |
| Casing Material | Stainless steel precision casting |
| Card Capacity | 20,000 |
| RS-485 | 1 |
| Wiegand | 1 (they can be set as an input or output port) 2 channels |
| Alarm Input Alarm Output |
2 channels |
| Power Output | 1 port (12 V, 500 mA) |
| Exit Button | 1 channel |
| Door Status Detection | 1 channel |
| Lock Control | 1 channel, open by default |
| Network Port | 1 × 10 Mbps/100 Mbps Ethernet port |
| Tamper Alarm | Yes |
| Unlock Password Mode | User, public and duress passwords |
| Appearance Color | Silver |
| Power Supply | 12 VDC, 2 A; Standard PoE |
| Power Adapter | Optional |
| Installation | Flush Mount;Wall Mount |
| Certifications | CE |
| Accessory | Power supply (optional); Flush mount box (optional) |
| Product Dimensions | 406 mm × 143 mm × 54.05 mm (15.98″ ×5.63″ × 2.13″) (H × W × D) |
| Protection | IP65 rated (Silicone sealant is required. See the quick start guide for more information). |
| Operating Temperature | –30 °C to +60 °C (–22 °F to +140 °F) |
| Operating Humidity | 0%–90% (RH), non-condensing |
| Operating Altitude | 0 m–1,300 m (0 ft–4265.09 ft) |
| Power Consumption | ≤5 W (standby), ≤18 W (working) |
| Gross Weight | 2.3 kg (5.07 lb) |
| Type | Model |
| Door Station | DHI-VTO6521 |
| Accessories | VTOB103 |
| VTM57R | Surface Mounted Box With Rain Cover |
