Description
Technical Specifications
| Model | TL-SG1218MPE |
|---|---|
| General | Interfaces |
| PoE | PoE Standard |
| PoE Ports | 16, up to 30 W Per Port |
| PoE Power Budget | 250 W* |
| Performance | Switching Capacity |
| Packet Forwarding Rate | 26.78 Mpps |
| Max Address Table | 8 K |
| Packet Buffer | 4.1 Mbit |
| Jumbo Frame | 10 KB |
| Physical & Environment | Power Supply |
| Maximum Power Consumption |
19.4 W (220V/50Hz. no PD connected) 293.3 W (220V/50Hz. with 250W PD connected) |
| Maximum Heat Dissipation | 66.15 BTU/h (no PD connected) 1000.15 BTU/h (with 250 W PD connected) |
| Dimensions (W×D×H) | 17.3 × 7.1 × 1.7 in. (440 × 180 × 44 mm) |
| Noise | Max: 47.8 dBA @50cm 25°C Min: 35.5 dBA @50cm 25°C |
| FAN Quantity | 2 |
| Operating Temperature | 0°C~50°C (32°F~122°F) |
| Storage Temperature | -40°C~70°C (-40°F~158°F) |
| Operating Humidity | 10%~90%RH, non-condensing |
| Storage Humidity | 5%~90%RH, non-condensing |
| Certification | CE, FCC |
| L2 Features | • Link Aggregation – Static link aggregation – Up to 8 aggregation groups and up to 4 ports per group • Loopback Detection • Port Statistics • Cable Test • Flow Control • Mirroring – Port Mirroring – Ingress/Egress/Both |
| IGMP Snooping | • IGMP v1/v2/v3 Snooping • 128 Max Multicast Entries |
| VLAN | • 802.1Q VLAN • Port Based VLAN • MTU VLAN |
| QoS | • Port Based, 802.1p Based, 802.1p QoS/ DSCP priority • Bandwidth Control – Ingress Rate/Egress Rate/Both • Storm Control – Broadcast/Multicast/Unknown-Unicast Control |
| PoE | • PoE Management • PoE Auto Recovery • Extend Mode |
