Description
The Hikvision DS-3E1510P-EI is a smart-managed PoE switch combining eight Gigabit PoE ports with two Gigabit uplink ports, making it ideal for powering IP cameras and network devices. It supports both IEEE 802.3af and 802.3at standards, delivering up to 30 W per port with a total PoE budget of 110 W. The switch also provides long-range PoE transmission up to 300 m, ensuring flexibility for extended installations. With a switching capacity of 20 Gbps, packet forwarding rate of 14.88 Mpps, and a 4K MAC address table, it offers reliable performance even under heavy network loads.
Built for dependable operation, the DS-3E1510P-EI includes 6 kV surge protection on PoE ports, ensuring resilience against electrical spikes. It supports advanced Layer-2 features such as VLANs, STP/RSTP loop prevention, link aggregation for redundancy, PoE watchdog for automatic reboot of unresponsive devices, and cable diagnostics for troubleshooting. These features make it a secure and stable choice for surveillance and business networks.
The switch can be managed through a user-friendly web interface or remotely via Hik-Partner Pro and Hik-Central Pro platforms. Administrators gain access to real-time monitoring of PoE usage, port status, bandwidth, alarms, and topology maps. Additional management tools such as DHCP, static IP, LLDP discovery, SNMP, port mirroring, and configuration backups further simplify network deployment and maintenance.
Compact and durable, the device features a fanless metal chassis for quiet operation and can be installed on a desk or wall. It operates reliably in temperatures between –10 °C and 55 °C, has a maximum power consumption of 120 W, and just 2.7 W when idle. With support for international standards such as CE, UL, CB, RoHS, and WEEE, the DS-3E1510P-EI provides a robust and efficient networking solution.
Key Features
- 8× Gigabit PoE ports (up to 30 W each) + 2× Gigabit uplink ports, with 110 W PoE budget
- Long-range PoE transmission up to 300 m
- 20 Gbps switching capacity, 14.88 Mpps throughput, and 4K MAC address table
- Advanced features: VLANs, STP/RSTP, link aggregation, PoE watchdog, cable diagnostics
- Remote management via Hik-Partner Pro and Hik-Central Pro with real-time monitoring
