Description
Technical Specifications
| Status Indicator Light | 4 |
|---|---|
| Communication Mode | 2-wire |
| Cascade Ability | 10 |
| Operating Altitude | 0-3000 m |
| Power Consumption | ≤ 15W (KIT) |
| Net Weight | 0.25 kg (0.55lb) |
| Gross Weight | 0.39 kg (0.86 lb) |
| port | Two 2-wire ports for cascade |
| port | Two RJ45 ports, 10 Mbps/100 Mbps Ethernet |
| port | One 2-wire device port |
| Casing | PC + ABS |
| Appearance color | White |
| Power Supply | DC 48V, 1A–3A |
| Power Adapter | Optional |
| Installation | Guide rail mount |
| Certifications | CE; FCC; UL |
| Accessory | Power converter cable |
| Product Dimensions | 131.1 mm × 103 mm × 40 mm (5.16″ × 4.06″ × 1.57″) |
| Operating Temperature | –10°C to +55°C (14°F to 131°F) |
| Operating Humidity | 10%–95% (RH, non-condensing) |
| Type | Model |
| 2-wire Switch | DHI-VTNS2003B-2 |
| Accessories | ADS-65LSI-52-1 48060G |
| EDP-240-48 | Power supply finished product-AC/ DC certified power supply-Power supply-AC100V~240V-48V5A |
