Description
Authentication – Levels of authentication PIN only, CARD only
Code – PIN code – 4 to 8 digits
Door type – Standard or narrow doors
Approvals – CE, EN14846, EN179 and EN1125 lock inside 280 x 46,5 x 25,7 outside 280 x 46,5 x 20,2 (H x W x D)
DIN direction –Left / right to be specified when ordering
Distance – Distance standard doors 72 mm / narrow doors 92 mm, spindle 8 mm. Spindle and attachment screw’s length to be specified when ordering
Door leaf thickness – Spindle length – Door thickness in: 47/50 (40- 54 mm); 57/50 (47/66 mm); 67/60 (61-80 mm); 74/50 (66-80 mm); 120/120 (88-100 mm); 80/50 (70-87 mm).
Battery – 4 x Lithium AAA
Battery life – > 28000 cycles (max. 6 months)
Radio standard – IEEE 802.15.4 (2.4 GHz)
Encryption (radio communication) – AES 128 bits
Distance between the RFID-Reader and hub – Up to 16 meters depending on the building environment
Operating temperature range – 10°C to 65°C
Relative humidity – < 85% (non-condensing)
Status – LED (red/green/blue)
Door status – Locking status (unlocked / locked); Door indication (closed / open); Inside handle detection; Key Cylinder use; Tamper (sabotage).
RFID Technologies (Based on reader type) – MIFARE® DESFire® EV1; Mifare Classik 1K
RFID reading – UID
RFID reading range – < 4 cm
Communication interfaces – Wireless software updates
Offline and Online operation modes – Codes and cards are synchronized to the lock, so the lock can be used when hub is offline.
Technical Specifications
| Delivery Duration | Special Order – Please Enquire For Lead Time |
|---|---|
| Brand | WebLock |
| Colour | White |
| Special Order | Yes |
