Description
Technical Specifications
| Product Model | VIGI SP9030 |
|---|---|
| Power | 90W |
| Voltage | 18V |
| Dimension | 998mm*516mm*30mm |
| Angle Adjustment (Manual) | 5°/15°/25°/35°/45°/55° |
| Type | Lithium |
| Intelligent Auxiliary Heat | Yes |
| Voltage | 10.8V |
| Capacity | 31.2Ah |
| Max. Output Voltage | 12.6V |
| Life | More than 500 cycles |
| Dimension | 242×70×65 mm (9.5×2.8×2.6 in) |
| Charging Condition | 0°C~45°C -30°C~45°C (With intelligent auxiliary heating) |
| Discharging Condition | -20°C~60°C -30°C~60°C(With intelligent auxiliary heating) |
| Quantity | 4 |
| Color | Blue |
| Description | 1*SYS Indicator 1*LAN Indicator 1*PV Indicator 1*BAT Indicator |
| Interface | 1*10/100M RJ45, 1*Photovoltaic Panel Connector |
| Load Interface | #1, #2: 9V-12.6 VDC/2A, #3: 12 VDC/2A 3* 5.5mm DC Power Plugs |
| Load Control | Yes |
| High and Low Temperature Protection | Yes |
| Overdischarge Protection | Yes |
| Power Consumption Statistics | Yes |
| Displays Real-time Load Status | Yes |
| Battery Level Display | Yes |
| Time Zone Selection | Yes |
| Region Selection | Yes |
| Schedule Saving | Yes |
| Firmware Remote Update | Yes |
| Remote Reboot | Yes |
| Local LAN Management | Yes |
| Smart Charging control | -30°C-5°C |
| Account Management | Yes |
| Web Management | No |
| Remote Reset | Yes |
| Remote Message Push | Yes |
| Certification | CB, PSE (Battery) CE, FCC, VCCI, IC, IP66 |
| Compatible Pole Diameter | Ø3.1-4.7 in (Ø80-120 mm) |
| Operating Temperature | -30°C-60°C (With intelligent auxiliary heating) |
| Operating Humidity | 10%~90%RH, Non-condensing |
| Package Size | 1110*615*225mm |
| Weight | 15kg |
| Package weight | 17.5kg |
| Package Contents | Quick Start Guide Waterproof Cable Attachments Mounting Accessories |
