Technical Specifications
| Product Model | VIGI NVR2016H-16MP |
|---|---|
| IP Video Input | 16-Channel |
| Incoming Bandwidth | 320 Mbps |
| Outgoing Bandwidth | 320 Mbps |
| HDMI Output Resolution | 1 Channel, Resolution: 3840×2160/30Hz, 1920×1080/60Hz, 1680×1050/60Hz, 1440×900/60Hz, 1280×1024/60Hz, 1280×720/60Hz |
| VGA Output Resolution | 1 Channel, Resolution: 1920×1080/60Hz, 1680×1050/60Hz, 1440×900/60Hz, 1280×1024/60Hz, 1280×720/60Hz |
| Video Output Mode | HDMI/VGA Independent Output |
| Multi-View Display | 1/4/6/8/9/16 |
| Audio Compression | G.711A/G.711U/G.726 |
| Video Compression | H.265+/H.265/ H.264+/H.264 |
| Record Resolution | 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback | 16-Channel† |
| Capability | •25fps: 10-ch @ 3MP, 16-ch @ 1080P •30fps: 4-ch @ 8MP, 6-ch @ 5MP, 8-ch @ 4MP |
| Record Mode | Manual Recording, Scheduling Recording, Motion Detection Recording |
| Playback Mode | Instant Playback, Rgular Playback, Tag Playback, Event Playback |
| Backup Mode | Regular Backup, Video Clip Backup |
| Playback Function | Play, Pause, Stop, Fast Forward, Fast Backward, Play By Frame, Full Screen, Video Clip, Export Clip, Digital Zoom, Lock Recording, Audio On/ Off |
| Network Protocols | UPnP (Plug and Play), NTP (Network Timing), SMTP, DNS, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP |
| Interoperability | ONVIF Profile S, CGI |
| Mobile Phone Access | Android, iOS |
| Browser | Chrome (57+), Firefox (52+), Edge (91+), Safari (11+) |
| Interface | 1-16, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface |
| Power | △ 140 W Available for All PoE+ Ports, 30 W Max per Port |
| Standard | 802.3at/af Compliant |
| Network Interface | 1, RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface |
| USB Interface | 1 Front USB 2.0 Port, 1 Rear USB 3.0 Port |
| Audio Interface | 1-ch RCA Input; 1-ch RCA Output |
| Alarm In/Out | 6/4 |
| Serial Interface | N/A |
| Power | 1× DC Jack |
| Reset Button | 1 |
| Speaker | N/A |
| eSATA | 1* |
| HDMI | 1 |
| VGA | 1 |
| SATA | 2 SATA Interfaces |
| Capacity | Up to 16 TB Capacity for Each HDD* |
| General Alarm | •Motion Detection •Video Tampering •Scene Change Detection •Line-Crossing Detection •Intrusion Detection •Region Entering Detection •Region Exiting Detection •Loitering Detection •Object Abandoned/Removal Detection •Vehicle Detection •Human Detection •Abnormal Sound Detection •Smart Frame Note: The alarm function requires the use of a camera. |
| Anomaly Alarm | •Video Loss •Offline and IP Conflict •Disk Exception •Login Exception •Fan Exception Note: The alarm function requires the use of a camera. |
| Alarm Linkage | •Recording •White Light Alarm •Buzzer •Log •Audible Alarm Note: The alarm function requires the use of a camera. |
| Package Contents | •VIGI Network Video Recorder •Power Adapter •Power Cables •HDD Power Cables •HDD Data Cables •Mounting Accessories •Mouse •Quick Installation Guide |
| Power Supply | DC 53.5V/3.37A |
| Max Power Consumption (Without Disk) |
6.2 W |
| Max Power Consumption (With Disk) | 40W |
| Working Temperature | •NVR: -10–55 °C •Power Adapter: 0–40 °C |
| Storage Temperature | -40-70 °C |
| Working Humidity | 10%~90% RH Non-Condensing |
| Storage Humidity | 10%~90% RH Non-Condensing |
| Product Dimensions (W × D × H) | 13.0 × 11.2 × 1.8 in (330 × 285 × 45 mm) |
| Net Weight | # 2.2 Kg |
| Gross Weight | # 4.2 Kg |
| Certification | CE, NTRA, BSMI, VCCI, FCC, HDMI, ONVIF |
