Technical Specifications
| Product Model | VIGI NVR1008H |
|---|---|
| IP Video Input | 8-Channel |
| Incoming Bandwidth | 80 Mbps |
| Outgoing Bandwidth | 60 Mbps |
| HDMI Output Resolution | 1 Channel, Resolution: 3840 ×2160/30Hz, 1920 × 1080/60Hz, 1680× 1050/60Hz, 1440 × 900/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
| VGA Output Resolution | 1 Channel, Resolution: 1920 × 1080/60Hz, 1680× 1050/60Hz, 1440 × 900/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
| Video Output Mode | HDMI/VGA Simultaneous Output |
| Multi-View Display | 1/4/6/8 |
| Audio Compression | G.711A/G.711U/G.726 |
| Video Compression | H.265+/H.265/ H.264+/H.264 |
| Record Resolution | 8 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Synchronous Playback | 8-Channel |
| Capability | 25fps: 2-ch @ 8MP, 4-ch @ 4MP, 8-ch @ 2MP 30fps: 4-ch @ 3MP, 2-ch @ 5MP |
| Record Mode | • Manual Recording • Scheduling Recording • Motion Detection Recording |
| Playback Mode | • Instant Playback • Regular Playback • Tag Playback • Event Playback |
| Backup Mode | • Regular Backup • Video Clip Backup |
| Playback Function | •Play •Pause •Stop •Fast Forward •Fast Backward •Play By Frame •Full Screen •Video Clip •Export Clip •Digital Zoom •Lock Recording •Audio On/Off |
| Network Protocols | UPnP (Plug and Play), NTP (Network Timing) |
| Interoperability | ONVIF, CGI |
| Mobile Phone Access | Android, iOS |
| Browser | Chrome (57+), Firefox (52+), Edge (91+) |
| Network Interface | 1, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface |
| USB Interface | 2× USB 2.0 |
| Audio Interface | 1-inch RCA Input; 1-inch RCA Output |
| Alarm In/Out | N/A |
| Serial Interface | N/A |
| Power | 1× DC Jack |
| Reset Button | 1 |
| Speaker | N/A |
| eSATA | N/A |
| HDMI | 1 |
| VGA | 1 |
| SATA | 1 SATA Interface |
| Capacity | Up to 16 TB Capacity for Each HDD |
| General Alarm | •Motion Detection •Video Tampering •Line-Crossing Detection •Intrusion Detection •Region Entering Detection •Region Exiting Detection •Object Abandoned/Removal Detection •Vehicle Detection •Human Detection •Smart Frame |
| Anomaly Alarm | •Video Loss •Offline and IP Conflict •Disk Exception •Login Exception |
| Alarm Linkage | •Recording •White Light Alarm •Buzzer •Log •Audible Alarm |
| Package Contents | •VIGI Network Video Recorder •Power Adapter •HDD Screws •Mouse •Rubber Feet •Quick Installation Guide |
| Power Supply | DC 12V/1.5A |
| Max Power Consumption (Without Disk) |
4.25 W |
| Working Temperature | •NVR: -10–55 °C •Power Adapter: 0–40 °C |
| Storage Temperature | -40-70 °C |
| Working Humidity | 10%~90% RH Non-Condensing |
| Storage Humidity | 10%~90% RH Non-Condensing |
| Product Dimensions (W × D × H) | 246.2 × 148.2 × 45 mm |
| Net Weight | 0.59 kg |
| Gross Weight | 0.95 kg |
| Certification | CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI |
