Description
The A-2240DD is a high cost-performance mixer power amplifier suited for broadcasting paging or background music in schools, offices, shops, factories, mosques, churches and large rooms.
Ideally suited for connection to a DVR/NVR for site waide broadcasts.
| A-2240DD-EB | |
|---|---|
| Power source |
220 – 240 V AC, 50 / 60 Hz |
| Rated output |
240 W |
| Frequency response |
50 Hz – 20 kHz (±3 dB) |
| Distortion |
< 1 % (at 1 kHz, 1/3 rated output power) |
| Power consumption |
48 W (EN 62368-1: AC operation at 1/8 rated output) |
| Amplifier |
Class D |
| S/N ratio |
60 dB (or more) |
| Number of channels |
1 |
| Connectable microphones |
3 |
| Inputs |
MIC 1: -60dBV, 600 Ohm, balanced, 5-pin DIN equivalent, phantom power selectable, + 21V |
| Control input |
Mute: via DIN jack |
| Outputs |
Speaker: balanced (floating) / Rec out: 0 dBV, 600 Ω, unbalanced, RCA Pin Jack |
| Finish |
ABS resin, Steel plate, black |
| Dimensions |
420 x 100.6 x 280.3 mm (W x H x D) |
| Weight |
4 kg |
Technical Specifications
| Delivery Duration | Next Day Delivery |
|---|---|
| Brand | TOA |
| Colour | Black |
| Special Order | No |
