Description
Technical Specifications
| Model | Nemesis N90 |
|---|---|
| Input | Voltage** |
| Frequency | 45-65Hz (Auto Sensing) |
| Power Factor | ≥0.99 (Full Linear Mode) |
| Generator Input | Supported |
| Input Connection | 10A, IEC 320-C14 |
| Capacity | N90/N180/270 when input voltage is 210~240Vac PF=0.9(900/1800/2700W) when input voltage is 185~260Vac PF=0.8(800/1600/2400W) when input voltage is 160~300Vac PF=0.7(700/1400/2100W) |
| Output | Voltage |
| Voltage Regulation | Within ±1% until low battery warning |
| Frequency Sync Range | 3Hz or 1Hz selectable |
| Frequency (battery Mode) |
50/60 Hz 0.1% unless synchronised to the line |
| Current Crest Ratio | 3:1 |
| Harmonic Distortion | <3% at full Linear Load, <7% at full Non-Linear Load |
| Output Waveform | Pure Sinewave |
| Outlets | (3)10A, IEC 320-C13 |
| Overload Capacity (tolerance ±1%) In Line Mode |
210~265VAC Derating PF=0.9 |
| 900W/100% | 1800W/100% |
| 800W/100% | 1800W/100% |
| 700W/100% | 1400W/100% |
| Battery Mode | <105% continuous 106-120% for 30 seconds shuts down 121-150% for 10 seconds shuts down >150% Immediately shuts down Buzzer continuously alarms |
| Bypass Mode | <105% continuous 106-120% for 250 seconds shuts down 121-130% for 125 seconds shuts down 131-135% for 50 seconds shuts down 136-145% for 20 seconds shuts down 146-148% for 5 seconds shuts down 149-157% for 2 seconds shuts down 158-176% for 1 second shuts down 177-187% for 0.32 of a Buzzer continuously alarms |
| Model | Nemesis N90 |
| Efficiency | Line Mode |
| Battery Mode | 85% |
| ECO Mode | 97% |
| Battery | Number of Batteries |
| Related Battery Voltage | 7Ah |
| Rated Battery Voltage | 36VDC |
| BBaacckk uupp tt ii mm ee ((LLiinneeaarr LLooaadd)) |
50% Load |
| 70% Load | >3min |
| 100% Load | >1min |
| C h a r g e current m a x |
Standard |
| External | 3A |
| Recharge Time (to 90%) | 4hr |
| Floating Mode Charging Voltage | 27.4VDC±1% |
| Bulk Mode Charging Voltage | 30VDC±1% |
| DC Leakage Current | ≤30μA with no AC applied and the unit in the off position |
| Transfer Time |
AC to DC |
| Inverter to Bypass | 4mS (Typical) |
| DC Start | Yes |
| Self Diagnosis |
Upon Power-on, Front panel settings & software control, 24 hours routine check |
| Front Panel | LCD |
| Button | Fault, Overload and Load/Battery Leve ON/OFF/Select/Silence |
| Alarm | Battery Mode |
| Low Battery | Sounds once every 0.2 seconds |
| Overload | Sounds once every 3 seconds |
| Normal alarm | Sounds once every 3 seconds |
| Fault | Continuous tone |
| Protection | Short Circuit |
| Battery | Normal Mode: Output Breaker/Electronic Circuit Battery Mode: Output Breaker/Electronic Circuit Battery Displacement Management |
| EPO | Shuts down UPS Immediately |
| Over Temperature | Normal Mode : Transfer to bypass mode Battery Mode: UPS Shuts down immediately |
| Physical | Dimensions (DxWxHmm) |
| Weight | 10kg |
| Environmental | Operating Temperature |
| Noise Level | ≤50dB |
| Relative Humidity | 0-90% (without condensation) |
| Interface | Standard |
| Option | EPO, 2nd RS232, USB, RS485, Dry contacts, SNMP/Web Card |
| Compatible Platforms | Microsoft Windows series, Linux, Mac, etc. |
| Standards and Certifications |
Safety |
| EMC | EN62040-2, EN61000-3-2, EN61000-3-3 |
| Marks | CE |
