Dahua Traffic Radar for use with Traffic Barrier - 79 GHz Anti-smashing Radar

Dahua

Dahua Traffic Radar for use with Traffic Barrier – 79 GHz Anti-smashing Radar

SKU DHI-ITSJC-2303-DC12

Out of stock

£267.30 ex VAT

£320.76 inc VAT

The 79 GHz anti-smashing radar adopts leading technologies of high precision microwave measurement and high speed digital signal processing, endowing it with high accuracy, free of commissioning, and high stability. The radar is ideal for working with boom barrier to monitor and control vehicles entry and exit, and prevent the barrier arm from hitting the vehicles or humans.

- Uses the latest algorithm to filter interference and is suitable for advertising barriers, fence arm barriers, straight arm barriers, and folding arm barriers.
- Adjustable detection distance and width, applicable to multiple scenes.
- Supports updating through serial port and mobile app (with Wi-Fi connection), and allows online commissioning and firmware update.
- The radar reads the surroundings automatically, which makes it applicable to complicated scenes.
- Connects to cameras through RS-485 to obtain parameters and working logs of the radar on camera web interface.

Key specifications

Emission Frequency
77 GHz–81 GHz
Emission Power
≤ 10 mW
Beam Width
Vertical: ± 10°, horizontal: ± 36°
Response Time
50 ms
Detection Region
0.3 m–6 m (0.98 ft–19.69 ft) (adjustable)
Anti-smashing Region
0 m–2 m (0 ft–6.56 ft) (adjustable)
Detection Target
Human, vehicle
Online Commissioning
Yes, through serial port or mobile app (with Wi-Fi connection)
Full specification

Description

Technical Specifications

Emission Frequency 77 GHz–81 GHz
Emission Power ≤ 10 mW
Beam Width Vertical: ± 10°, horizontal: ± 36°
Response Time 50 ms
Detection Region 0.3 m–6 m (0.98 ft–19.69 ft) (adjustable)
Anti-smashing Region 0 m–2 m (0 ft–6.56 ft) (adjustable)
Detection Target Human, vehicle
Online Commissioning Yes, through serial port or mobile app (with Wi-Fi
connection)
Update Yes, through serial port or mobile app (with Wi-Fi
connection)
RS-485 1
I/O 2 (1 for update input, 1 for relay output)
Operating voltage 9 V–12 V DC
Operating Current < 0.25 A
Power Consumption < 3 W
Operating Temperature –40 °C to +85 °C (–40 °F to +185 °F)
Protection Grade IP66
Product Dimensions 96 mm × 60 mm × 16.4 mm (3.78″ × 2.36″ × 0.65″)
(L × W × H)
Net Weight 70 g ± 10 g (0.15 lb ± 0.02 lb)
Gross Weight 220 g ± 20 g (0.49 lb ± 0.04 lb)
Installation Case side mount
Type Model
Anti-smashing
radar		 DHI-ITSJC-2303-DC12
Accessories SOY-1200330L

Additional information

Brand

Dahua
Colour

White
