Description
Technical Specifications
| Main Processor | Embedded Processor |
|---|---|
| Operating System | Embedded Linux Operation System |
| Button Type | Mechanical |
| Interoperability | ONVIF; CGI |
| Network Protocol | SIP; TCP; RTP; UPnP; P2P; DNS; UDP; RTSP; IPv4 |
| Camera | 1/2.9″ 2 MP CMOS |
| Field of View | H: 168.6°; V: 87.1°; D: 176.7° |
| WDR | 120 dB |
| Noise Reduction | 3D NR |
| Video Compression | H.265; H.264 |
| Video Resolution | Main stream: 720p; WVGA; D1; CIF Sub stream: 1080p; WVGA; D1; QVGA; CIF |
| Video Frame Rate | 25 fps |
| Video Bit Rate | 256 kbps to 8 Mbps |
| Light Compensation | Auto IR |
| Day/Night | Auto(ICR)/Color/B/W; Color/B/W |
| Audio Compression | G.711a; G.711u; PCM |
| Audio Input | 1 channel |
| Audio Output | Built-in speaker |
| Audio Mode | Two-way audio |
| Audio Enhancement | Echo suppression/digital noise reduction |
| Audio Bit Rate | 16 kHz, 16 bits |
| Communication Mode | Full digital |
| Unlock Mode | Remote |
| Leave Videos | Yes (SD card is inserted in the indoor monitor or door station) |
| Storage | Supports Micro SD card (up to 256 GB) |
| Web Configuration | Yes |
| Casing Material | Aluminum |
| RS-485 | 1 |
| Alarm Output | 1 |
| Power Output | 1 port (12 V, 600 mA) |
| Exit Button | 1 |
| Door Status Detection | 1 |
| Lock Control | 1 |
| Network Port | 1 × RJ-45 port, 10/100 Mbps network port |
| Tamper Alarm | Yes |
| Appearance Color | Silver |
| Power Supply | 48 VDC, 0.4 A; PoE (802.3af/at) |
| Power Adapter | Optional |
| Installation | Surface mount (The surface mount kit comes with the surface mount bracket) |
| Certifications | CE |
| Product Dimensions | 200.0 mm × 98.0 mm × 35.4 mm (7.87″ × 3.86″ × 1.39″) |
| Protection | IK08, IP65 (Silicone sealant is needed, see the quick start guide) |
| Operating Temperature | –40 °C to +60 °C (–40 °F to +140°F) |
| Operating Humidity | 10%–95% (RH), non-condensing |
| Operating Altitude | Beneath 3000 m (9842.52 ft) |
| Operating Environment | Outdoor |
| Power Consumption | ≤5 W (standby), ≤7 W (working) |
| Gross Weight | 692 g (1.53 lb) |
| Storage Humidity | 30%–75% (RH) |
| Storage Temperature | 0 °C to +40 °C (+32 °F to +104 °F) |
| Main Processor | Embedded Processor |
| Operating System | Embedded Linux Operation System |
| Screen Type | Capacitive Touchscreen |
| Display Screen | 7″ TFT |
| Screen Resolution | 1024 (H) × 600 (V) |
| Audio Compression | G.711a; G.711u; PCM |
| Audio Input | 1-channel all-direction microphone |
| Audio Output | Built-in 1.5 W loudspeaker |
| Audio Mode | Two-way audio |
| Audio Enhancement | Echo suppression/digital noise reduction |
| Audio Bit Rate | 16 kbps |
| Communication Mode | Full digital |
| Information Release | Supports to receive and view notifications issued by center |
| Leave Videos | Yes |
| DND Mode | Do not disturb period can be set |
| Number of Extensions | 9 |
| Storage | Embedded 8 GB card |
| Alarm Input | 6 channel (switch quantity) |
| Alarm Output | 1 channel |
| Network Port | 1 × RJ-45 port |
| SOS Alarm | Yes |
| Casing Material | PC + ABS |
| Appearance Color | Black |
| Power Supply | 12 VDC, 1 A, PoE |
| Installation | Surface Mount |
| Certifications | CE; FCC; UL |
| Accessory | Default bracket Default alarm cable |
| Product Dimensions | 119.6 mm × 221.5 mm × 21.5 mm (4.71″ × 8.72″ × 0.85″) |
| Operating Temperature | -10°C to +55°C (+14°F to +131°F) |
| Operating Humidity | 10%-95% (RH), non-condensing |
