Description
Technical Specifications
| Lifespan | 30,000 hrs |
|---|---|
| Operation Hours | 7 × 24 h |
| Input Port | 1 × VGA (1920 × 1080@60 Hz), 1 × HDMI 1.4 (1920 × 1080@100 Hz) |
| Power Supply | 12 VDC, 2 A |
| Power Type | External power adapter |
| Power Consumption | 14.5 W (basic), 20.5 W (typ.), 21 W (max) |
| Standby Power Consumption |
<0.5 W |
| Operating Temperature | 0 °C to +40 °C (+32 °F to +104 °F) |
| Operating Humidity | 10% – 85% (RH) |
| Storage Temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
| Storage Humidity | 5%–90% (RH) |
| Model | DHI-LM22-L200N |
| LCD Technology | VA |
| Backlight | ELED |
| Screen Size | 21.45 inch |
| Aspect Ratio | 16:9 |
| Viewing Size | 478.656 (H) × 260.28 (V) mm |
| Viewing Angle | 178° (H) / 178° (V) |
| Display Mode | Horizontal |
| Pixel Pitch | 0.2493 mm × 0.241 mm |
| Pixels Per Inch | 102.69 |
| Resolution | 1920 (H) × 1080 (V) |
| Refresh Rate | 100 Hz |
| Display Color | 8 bit |
| Color Gamut | 72% NTSC (typ.) |
| Brightness | 250 cd/m² (typ.) |
| Contrast Ratio | 3000:1 |
| Response Time | OD 5 ms |
| Inclined Angle | –5° ± 2°/15° ± 2° |
| Product Dimensions | 493.1 mm × 290.8 mm × 50.4 mm (19.41″ × 11.45″ × 1.98″) (W × H × D) without base |
| Package Size | 557 mm × 370 mm × 140 mm (20.87″ × 13.98″ × 4.88″) (W × H × D) |
| Frame Width | U/L/R/D: 2.0 mm/2.0 mm/2.0 mm/22.1 mm (0.08″/ 0.08″/0.08″/0.87″) |
| Net Weight | 2.3 kg (5.07 lb) |
| Gross Weight | 3.4 kg (7.50 lb) |
| Casing Color | Black |
| Control Mode | Five-button |
| Wall Mount VESA | 100 mm × 100 mm (3.94″ × 3.94″) |
| Accessory | Power adapter, base, HDMI cable, user’s manual (QR code), QSG, legal and regulatory information, etc. |
| Optional Accessory | Wall mount |
| Certifications | CE EMC, CE LVD, CE ERP |
| Type | Model |
| LED Monitor | DHI-LM22-L200N |
