Description
Technical Specifications
| Frequency Range | 13.56 MHz |
|---|---|
| Max. Transmission Power | 42dBuA/m @10m |
| Main Processor | Embedded Processor |
| Button Type | Touch button |
| Network Protocol | IPv4;RTSP;UDP;P2P;RTP;TCP;SIP |
| OSDP Protocol | Yes |
| Interoperability | ONVIF;CGI |
| SDK and API | Yes |
| Max. Transmission Power | ≤20dBm@2400-2483.5 MHz |
| Wi-Fi | Yes |
| Wireless Standard | IEEE802.11b/802.11g/802.11n |
| Wireless Frequency Range | 2.4 GHz |
| Card Reading Distance | 0 cm–3 cm (0″–1.18″) |
| Face Recognition Height Range |
1.1 m–2.0 m (3.61 ft–6.56 ft) |
| Face Recognition Distance | 0.3 m–1.5 m (0.98 ft–4.92 ft) |
| Face Recognition Accuracy | 99.9% |
| Face Recognition Time | 0.2s |
| Product Type | Standalone |
| Display Screen | 4.3-inch display screen |
| Screen Type | Capacitive Touchscreen |
| Screen Resolution | 480 (H) × 800 (V) |
| Camera | 2-MP CMOS HD dual-lens camera |
| WDR | DWDR |
| Light Compensation | Auto IR |
| Voice Prompt | Yes |
| Speaker | Yes |
| Casing Material | PC + GF |
| User (Card) Type | Normal user; VIP users; patrol users; guest user; blocklist user; other user; custom user 1; custom user 2 |
| Face Image Capacity | 6,000 |
| User Capacity | 6,000 |
| Card Capacity | 10,000 |
| Password Capacity | 6,000 |
| Record Capacity | 300,000 |
| Verification Method | Card;Password;Remote;QR Code;Face Recognition |
| Door Open Notification Mode |
Quick mode;Simple mode;Standard mode;Comparison mode |
| Period List | 128 periods |
| Holiday Period | 128 periods |
| Network Update | Yes |
| First User Unlock | Yes |
| Remote Verification | Yes |
| Restricted List/Trusted List | Yes |
| Advertisement Playing | Plays advertisements in video and image format |
| Peripheral Card Reader | 1 × RS-485 card reader 1 × Wiegand card reader |
| Multi-user Authentication | Yes |
| Real-time Monitoring | Yes |
| Multi-factor Authentication | Yes |
| Capture Function | Yes |
| Web Configuration | Yes |
| Auto Registration | Yes |
| RS-485 | 1 |
| Wiegand | 1 |
| USB | 1 |
| Network Port | 1 × RJ-45 10/100 Mbps self-adaptive Ethernet port |
| Alarm Input | 1 |
| Alarm Output | 1 |
| Alarm Linkage | Yes |
| Exit Button | 1 |
| Door Status Detection | 1 |
| Lock Control | 1 |
| Power Output Port | 1 |
| Anti-pass Back | Yes |
| Tamper Alarm | Yes |
| Duress Alarm | Yes |
| Door Sensor Timeout | Yes |
| Intrusion | Yes |
| Card Type | IC card;Desfire card (EV3,Compatible with Dahua card by default) |
| Modulation Type | ASK |
| Illegal Card Exceeding Threshold |
Yes |
| Power Adapter | Included |
| Power Supply | Standard PoE 12 VDC, 2 A |
| Protection | IP65 |
| Power Consumption | ≤24W |
| Product Dimensions | 180.1 mm × 90.1 mm × 27.0 mm (7.09″ × 3.55″ × 1.06″) (L × W × H) |
| Packaging Dimensions | 268 mm × 136 mm × 78 mm (10.55″ × 5.35″ × 3.07″) (L × W × H) (in an inner carton) 590 mm × 432 mm × 302 mm (23.23″ × 17.01″ × 11.89″) (L × W × H) (protection box) |
| Transport Package Dimensions |
590 mm × 432 mm × 302 mm (23.23″ × 17.01″ × 11.89″) (L × W × H, protection box) |
| Operating Temperature | –30 °C to +45 °C (–22 °F to +113 °F) |
| Operating Humidity | 0%–90% (RH), non-condensing |
| Operating Altitude | 0 m–1,300 m (0 ft–4265.09 ft) |
| Operating Environment | Indoor;Outdoor |
| Gross Weight | 0.70 kg (1.54 lb) |
