Description
Technical Specifications
| Layer | Layer 2 |
|---|---|
| Managed | No |
| Standard Power Supply | Yes |
| PoE | No |
| Ethernet Port | 8 |
| Ethernet Port Rate | 1 Gbps |
| Power Supply | 5V/1A DC |
| Operating Temperature | -10°C to 55°C (14°F to 131°F) |
| Operating Humidity | 10%–90% |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Storage Humidity | 10%–90% |
| Power Consumption | Idling: 0.81W Full load: 4W |
| Switching Capacity | 16 Gbps |
| Packet Forwarding Rate | 11.9 Mpps |
| Packet Buffer Memory | 1.5 Mbits |
| MAC Table Size | 2K |
| Standards Compliance | IEEE 802.3i, IEEE 802.3u, IEEE802.3ab, IEEE802.3x |
| ESD | Air discharge: 8kV Contact discharge: 4kV |
| Thunderproof | Common mode: 2kV |
| Net Weight | 0.11 kg (0.24 lb) |
| Gross Weight | 0.22 kg (0.49 lb) |
| Dimensions | 125 mm × 65 mm × 22 mm (4.92″ × 2.56″ × 0.87″ ) |
| Packaging Dimensions | 128 mm × 77 mm × 78 mm (5.04″ × 3.03″ × 3.07″ ) |
Reviews
There are no reviews yet.
