Description
Technical Specifications
| Operating Humidity | 10%–90% (RH) |
|---|---|
| Storage Temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
| Storage Humidity | 10%–90% (RH) |
| Product Dimensions | 39 mm × 33 mm × 19 mm (1.54″ × 1.30″ × 0.75″) |
| Packaging Dimensions | 95 mm × 59.5 mm × 30.5 mm (3.74″ × 2.34″ × 1.20″) |
| Net Weight | 45 g (0.10 lb) |
| Gross Weight | 60 g (0.13 lb) |
| Installation | Wall mount |
| Casing Material | PC + ABS |
| Certifications | CE |
| Alarm Input | 1 for tamper, NO/NC |
| Relay Output | 1, NO/NC (0–36 VDC, Max 5A) |
| Indicator Light | 1 for multiple statuses (pairing, communication) |
| Button | 1 |
| Remote Update | Cloud update |
| Test Mode | Yes |
| Carrier Frequency | 868.0 MHz–868.6 MHz |
| Communication Mechanism | Two-way |
| Communication Distance Encryption Mode |
1200 m (3937.01 ft) in open areas AES128 |
| Power Supply | 7–24 VDC |
| Operating Temperature | –10 °C to +55 °C (+14 °F to +131 °F) (indoor) |
