Description
Technical Specifications
| Low Battery Alarm | Yes |
|---|---|
| Search | Signal strength detection |
| Carrier Frequency | 868.0 MHz–868.6 MHz |
| Transmitter Power (EIRP) | Limit 25 mW |
| Communication Distance | Up to 1,600 m (5249.34 ft) in an open space |
| Communication Mechanism | Two-way |
| Encryption Mode | AES128 |
| Frequency Hopping | Yes |
| Power Supply | 12 VDC, 1.5 A |
| Battery Life | Battery standby time: 35 h |
| Operating environment | –10 °C to +55 °C (+14 °F to +131 °F) (indoor) |
| Operating Humidity | 10%–90% (RH) |
| Product Dimensions | 163.0 mm × 163.0 mm × 32.0 mm (6.42″ × 6.42″ × 1.26″) |
| Packaging Dimensions | 219.0 mm × 187.0 mm × 91.0 mm (8.62″ × 7.36″ × 3.58″) |
| Installation | Wall mount; Desktop |
| Net Weight | 0.32 kg (0.71 lb) |
| Gross Weight | 0.74 kg (1.63 lb) |
| Certifications | CE EN 50131-1:2006+A1:2009+A2:2017+A3:2020 EN 50131-3:2009 EN 50131-6:2017 EN 50131-5-3:2017 EN 50131-10:2014 EN 50136-2:2013 Security Grade 2 Environmental Class II |
| Casing | PC+ABS |
| Wireless Zone | 32 × wireless peripherals |
| Storage Battery | Built-in lithium battery |
| Indicator Light | 1 that indicates pairing and working |
| Power Switch | 1 × power switch |
| Pairing Mode | Auto/Manual |
| Tamper Alarm | Yes |
| Remote Update | Cloud update |
| Power Failure Protection for Configured Parameters |
Yes |
| Disconnection Detection of External Power Supply |
Yes |
| Type | Model |
| Alarm Accessory | DHI-ARA43-W2(868) |
