Description
How to set up a 1-1 VTO & VTH
Using a Dahua VTO2311 Villa Station and a VTH2421 indoor monitor, Connor walks through the full setup process using Dahua Config Tool and the VTO web interface. This step-by-step guide helps installers quickly get a simple door entry system up and running.
How to Set Up Intercoms Using Dahua’s Config Tool
In this config video, Connor walks through the complete setup of Dahua intercom devices using the Config Tool. Rather than configuring each device individually, we’ll show how to quickly deploy and associate multiple VTO door stations and VTH indoor monitors from a single interface, making installation faster and easier.
Technical Specifications
| Main Processor | High performace embedded processor |
|---|---|
| Operating System | Embedded LINUX OS |
| Screen Type | Capacitive screen |
| Display | 7-inch TFT screen |
| Resolution | 1024 × 600 |
| Video Compression | H.264 |
| Audio Compression | G.711A/G.711U/PCM |
| Audio Input | 1 channel all-direction microphone |
| Audio Output | Built-in 1.5W loudspeaker |
| Audio Mode | Support dual-way bidirectional talk |
| Audio Enhancement | Support echo cancellation/DNR |
| Audio Bit Rate | 16 kbps |
| Communication Mode | Full digital |
| Information Release | Support to receive and view notifications issued by center |
| Leave Videos or Text Messages | Support |
| DND Mode | Support to set DND period |
| Sub-station Quantity | 9 |
| Alarm Input | 6 channel (switch quantity) |
| Alarm Output | 1 channel |
| Network | 1 RJ-45 |
| SOS Alarm | Support |
| Casing | PC+ABS |
| Appearance Color | Appearance Color |
| Power Supply | Standard PoE DC 12V 1A |
| Installation | Wall mount |
| Accessories | Default bracket Default alarm cable |
| Dimensions | 119.6 mm × 221.5 mm × 21.5 mm (4.71″ × 8.72″ × 0.85″) |
| Operating Temperature | -10°C to +55°C (+14°F to +131°F) |
| Operating Humidity | 10%RH-95%RH |
| Power Consumption | Standby≤4W, work≤6W |
| Gross Weight | 0.35 Kg (0.77 lb) |
| Power supply mode | PoE |
| Storage | Support Micro SD, maximum memory capacity 32 G, standard memory capacity 8 G |
