Description
Technical Specifications
| Contrast Ratio | 1000:1 |
|---|---|
| Response Time | OD 5 ms |
| Lifespan | 50,000 hrs |
| Surface Treatment | Haze 25%, 3H |
| Flicker-free Technology | Yes |
| Input Port | 1 × VGA (1920 × 1080@75 Hz), 1 × HDMI 1.4 (1920 × 1080@100 Hz) |
| Output Port | 1 × Audio out |
| Speaker | 2 × 2 W |
| Model | DHI-LM22-J200 |
| LCD Technology | IPS |
| Backlight | ELED |
| Screen Size | 21.5 inch |
| Aspect Ratio | 16:9 |
| Viewing Size | 476.064(H) mm × 267.786(V) mm |
| Screen-to-Body Ratio | ≥85% |
| Viewing Angle | 178° (H) / 178° (V) |
| Display Mode | Horizontal |
| Pixel Pitch | 0.24795(H) × 0.24795(V) |
| Pixels Per Inch | 102.46 |
| Resolution | 1920 (H) × 1080 (V) |
| Refresh Rate | 100 Hz |
| Display Color | 8 bits |
| Color Gamut | 50% NTSC(typ.) |
| Brightness | 250 cd/m² (typ.) |
| Power Supply | 12 VDC, 2 A |
| Power Type | External power adapter |
| Power Consumption | 9.0 W (basic), 10.4 W (typ.), 13.6 W (max) |
| Standby Power Consumption |
<0.5 W |
| Operating Temperature | 0 °C to +40 °C (+32 °F to +104 °F) |
| Operating Humidity | 10%–85% (RH), non-condensing |
| Storage Temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
| Storage Humidity | 5%–90% (RH), non-condensing |
| Inclined Angle | -6° ± 3° / 27° ± 3° |
| Product Dimensions | 489.9 mm × 294.1 mm × 37.5 mm (19.29″ × 11.58″ × 1.48″) (W × H × D), without base |
| Package Size | 556 mm × 375 mm × 107 mm (21.89″ × 14.76″ × 4.21″) (W × H × D) |
| Frame Width | U/L/R/D: 2.4 mm/2.4 mm/2.4 mm/17.9 mm (0.09″/ 0.09″/0.09″/0.71″) |
| Net Weight | 2.5 kg (5.51 lb) |
| Gross Weight | 3.4 kg (7.50 lb) |
| Casing Color | Black |
| Control Mode | Five-button |
| Status Indicator Light | Yes |
| Wall Mount VESA | 75 mm × 75 mm (2.95″ × 2.95″) |
| Accessory | Power adapter, base, HDMI cable, user’s manual (QR code), QSG, legal and regulatory information, etc. |
| Optional Accessory | Wall mount |
| Certifications | CE EMC, CE LVD, CE ERP |
| Type | Model |
| LED Monitor | DHI-LM22-J200 |
