Description
| Sensitive element | PIR sensor (motion) electret microphone (glass break) |
| Motion detection distance | Up to 12 m |
| Motion detector viewing angles (H/V) | 88.5° / 80° |
| Pet immunity |
Yes, weight up to 20 kg, height up to 50 cm Why motion detectors react to animals and how to avoid it > |
| Glass break detection distance | Up to 9 m |
| Microphone coverage angle | 180° |
| Tamper protection | Yes |
| Frequency band | 868.0 – 868.6 MHz or 868.7 – 869.2 MHz depending on the region of sale |
| Compatibility | Operates with Hub, Hub Plus, Hub 2, ReX, ocBridge Plus, uartBridge |
| Maximum RF output power | Up to 20 mW |
| Radio signal modulation | GFSK |
| Radio signal range | Up to 1,200 m (any obstacles absent) |
| Power supply | 1 battery CR123A, 3 V |
| Вattery life | Up to 5 years |
| Installation method | Indoors |
| Operating temperature range | From -10°С to +40°С |
| Operating humidity | Up to 75% |
| Overall dimensions | 110 × 65 × 50 mm |
| Weight | 92 g |
| Certification | Security Grade 2, Environmental Class II in conformity with the requirements of EN 50131-1, EN 50131-2-7-1, EN 50131-2-2, EN 50131-5-3 |
Technical Specifications
| Delivery Duration | Next Day Delivery |
|---|---|
| Brand | AJAX |
| Colour | White |
| Special Order | No |
| AJAX Range | Fibra |
| Ajax Device Type | Motion Protect |
| Internal / External | Internal |
