Description
Technical Specifications
| Model | WI-PS305G |
|---|---|
| V2 | V2 |
| 4 1000Mbps RJ45 PoE Ports |
8 1000Mbps RJ45 PoE Ports |
| 1 1000Mbps RJ45 Port | 2 1000Mbps RJ45 Ports |
| Port 1- 4 | Port 1- 8 |
| Port 1: 802.3bt 60 W Port 2-4: 802.3af/at |
Port 1: 802.3bt 60 W Port 2-8: 802.3af/at |
| Port 1：60W max. Port 2-4: 30W Max. Total PoE power budget: 63 W max. |
Port 1：60W max. Port 2-4: 30W Max. Total PoE power budget: 118 W max. |
| 12 Gbps | 20 Gbps |
| 8.93 Mpps | 14.88 Mpps |
| AC 100-240V 1A | AC 100-240V 1.4A |
| dle: 2 W 100% Traff ic Rate with PoE: 65 W |
Idle: 2 W 100% Traff ic Rate with PoE: 120 W |
| Model | WI-PS305G |
| P On: The device power on is normal Off: The device is power off or failed PoE On: PoE is working Off: PoE not working Link On: Data on TX/RX Off: Ports link down E On: DIP switch is enabled in Extend mode V On: DIP switch is enabled in VLAN mode 1000M On: The negotiate speed is 1000Mbps and ports link up Off: The negotiate speed is 10/100Mbps, not 1000Mbps |
P On: The device power on is normal Off: The device is power off or failed PoE On: PoE is working Off: PoE not working Link On: Data on TX/RX Off: Ports link down E On: DIP switch is enabled in Extend mode V On: DIP switch is enabled in VLAN mode 1000M On: The negotiate speed is 1000Mbps and ports link up Off: The negotiate speed is 10/100Mbps, not 1000Mbps |
| 190x131x33mm | 210x151x33mm |
| Net Weight: 0.62 kg | Net Weight: 0.79 kg |
| Package Weight: 1.045 kg | Package Weight: 1.21 kg |
| Model | WI-PS305G |
| Model | WI-PS310GF |
| V1 | V1 |
| 8 1000Mbps RJ45 PoE Ports |
16 1000Mbps RJ45 PoE Ports |
| 2 1000Mbps SFP Slots | 2 1000Mbps SFP Slots |
| Port 1- 8 | Port 1- 16 |
| 30W Max. for each port, 146 W Max. for PoE power budget |
30W Max. for each port, 295 W Max. for PoE power budget |
| 20 Gbps | 36 Gbps |
| 14.88 Mpps | 26.78 Mpps |
| AC 110-240V 1.8A DC 37-57V |
AC 100-240V 3.6A |
| Idle: 4 W 100% Traff ic Rate with PoE: 150 W |
Idle: 5 W100% Traff ic Rate with PoE: 300 W |
| Model | WI-PS310GF |
| POWER On: The device power on is normal Off: The device is power off or failed PoE On: PoE is working Off: PoE not working Link On: Data on TX/RX Off: Ports link down 9、10(SFP) Blinking: Indicates that the Switch is actively sending or receiving data over that port. On: Indicates the link through that port is successfully established at 10/100/1000Mbps. Off: No device is connected to the corresponding port. |
PWR On: The device power on is normal Off: The device is power off or failed PoE On: PoE is working Off: PoE not working Link/Act On: Data on TX/RX Off: Ports link down 1000M On: The negotiate speed is 1000Mbps and ports link up Off: The negotiate speed is 10/100Mbps, not 1000Mbps |
| 280x140x44mm | 440x291x44mm |
| Net Weight: 0.97 kg | Net Weight: 3.23 kg |
| Package Weight: 1.555 kg | Package Weight: 4.01 kg |
